2026 RAV4 Hybrid 2.0L 4WD Luxury Edition
1. All-road Capable Hybrid Power: 5th-gen THS + E-Four 4WD, 144kW combined output
2. Spacious Practical Cabin: 2690mm wheelbase and 580L luggage compartment
3. Comprehensive Safety Configuration: TSS 3.0 L2 ADAS and full 9-airbag layout
Product Details
| Basic Information | |
| Manufacturer | FAW Toyota |
| Vehicle Class | Compact SUV |
| Energy Type | Gasoline |
| Launch Date | Nov-25 |
| Engine | 2.0L 171Ps Inline 4 |
| Max Power(kW) | 126kW (171 Horsepower) |
| Max Torque(N·m) | 206 N·m |
| Transmission | 10-speed Simulated CVT |
| L×W×H (mm) | 4620×1855×1680 |
| Body Structure | 5-door 5-seat SUV |
| Max Speed(km/h) | 180 km/h |
| WLTC Combined Fuel Consumption | 6.65 L per 100km |
| Vehicle Warranty | 3 Years or 100,000 km |
| Body | |
| Length (mm) | 4620 |
| Width (mm) | 1855 |
| Height (mm) | 1680 |
| Wheelbase (mm) | 2690 |
| Front Track (mm) | 1600 |
| Rear Track (mm) | 1620 |
| Body Type | SUV |
| Door Quantity | 5 Doors |
| Door Opening Type | Conventional Door |
| Seating Capacity | 5 Seats |
| Curb Weight (kg) | 1685 kg |
| Gross Vehicle Weight (kg) | 2150 kg |
| Fuel Tank Capacity (L) | 55 Liters |
| Min Turning Radius | 5.7 Meters |
| Engine | |
| Engine Code | M20D |
| Displacement (mL) | 1987 mL |
| Displacement (L) | 2.0 L |
| Intake Type | Naturally Aspirated |
| Engine Layout | Transverse Layout |
| Cylinder Arrangement | Inline |
| Cylinder Count | 4 Cylinders |
| Valves Per Cylinder | 4 Valves |
| Compression Ratio | 13.0:1 |
| Valve Train | Dual Overhead Camshaft |
| Max Horsepower (Ps) | 171 Ps |
| Max Power (kW) | 126 kW |
| Max Net Power (kW) | 126kW (171Ps) |
| Max Power RPM | 6600 rpm |
| Max Torque (N·m) | 206 N·m |
| Max Torque RPM | 4600–5000 rpm |
| Exclusive Engine Tech | Variable Valve Timing-intelligent |
| Fuel Type | Gasoline |
| Fuel Grade | 92 Octane |
| Fuel Supply | Combined Injection |
| Cylinder Head Material | Aluminum Alloy |
| Cylinder Block Material | Aluminum Alloy |
| Emission Standard | China National VI |
| Transmission | |
| Transmission Description | 10-speed Simulated Continuously Variable Transmission |
| Gear Quantity | Stepless Variable |
| Transmission Type | CVT Continuously Variable Transmission |
| Chassis & Steering | |
| Drive Layout | Front-engine All-Wheel Drive |
| 4WD Type | On-demand AWD |
| Center Differential | Multi-plate Clutch Center Differential |
| Front Suspension | MacPherson Independent Suspension |
| Rear Suspension | Double Wishbone Independent Suspension |
| Steering Type | Electric Power Steering |
| Chassis Structure | Unibody Construction |
| Wheels & Brakes | |
| Front Brake Type | Ventilated Disc Brake |
| Rear Brake Type | Solid Disc Brake |
| Parking Brake Type | Electronic Parking Brake |
| Front Tire Spec | 235/60 R18 |
| Rear Tire Spec | 235/60 R18 |
| Spare Tire Spec | ● Temporary Spare Tire |
| Spare Tire Location | ● Hidden Storage |
| Active Safety | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Anti-lock Braking System | ● Standard |
| Electronic Brake Force Distribution | ● Standard |
| Brake Assist | ● Standard |
| Traction Control System | ● Standard |
| Vehicle Stability Control | ● Standard |
| Active Safety Warning System | LDW, FCW, RCW, RCTA, Door Opening Warning |
| Automatic Emergency Braking | ● Standard |
| Blind Spot Assist | ● Standard |
| Lane Keeping Assist | ● Standard |
| Lane Centering Assist | ● Standard |
| Driver Fatigue Reminder | ● Standard |
| Active DMS Fatigue Monitoring | ● Standard |
| Traffic Sign Recognition | ● Standard |
| Passive Safety | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Front Airbags | Driver & Passenger Front Airbags |
| Side Airbags | Front Side Airbags |
| Side Curtain Airbags | ● Standard |
| Front Knee Airbag | Driver Knee Airbag |
| Center Airbag | Front Center Airbag |
| Seatbelt Reminder | ● Standard |
| Tire Pressure Monitoring System | Real-time Tire Pressure Display |
| ISOFIX Child Seat Anchors | ● Standard |
| Driving Assist & Control | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Parking Radar | Front & Rear Parking Radars |
| Driving Assist Camera | Rear View Camera, 360° Panoramic View |
| Cruise Control | CC, ACC, Full-speed ACC |
| ADAS Level | ● Level 2 ADAS |
| Auto Hold | ● Standard |
| Hill-start Assist Control | ● Standard |
| Hill Descent Control | ● Standard |
| Engine Auto Start-Stop | ● Standard |
| Low-speed 4WD | ● Standard |
| Drive Mode Selection | Sport, Off-road, Snow, Custom, ECO, Comfort |
| Exterior Configuration | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Sunroof Type | ● Panoramic Sliding Sunroof |
| Alloy Wheels | ● Standard |
| Interior Configuration | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Steering Wheel Material | Genuine Leather |
| Steering Wheel Adjustment | Tilt & Telescopic |
| Steering Wheel Controls | Multi-function Buttons |
| Shift Type | Mechanical Gear Lever |
| Instrument Cluster Type | Full LCD Instrument Cluster |
| LCD Cluster Size (inch) | 8.8 Inches |
| Comfort & Anti-theft | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Power Tailgate | ● Standard |
| Tailgate Position Memory | ● Standard |
| Engine Immobilizer | ● Standard |
| Central Door Lock | ● Standard |
| Key Type | Smart Key, Bluetooth Key, NFC Key |
| Keyless Entry | Front Doors Only |
| Push-button Start | ● Standard |
| Remote Start | ● Standard |
| Factory ETC | ● Standard |
| Wireless Phone Charger | Front Row 50W Wireless Charger |
| Trunk 12V Outlet | ● Standard |
| Seat Configuration | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Seat Upholstery | Synthetic Leather |
| Seat Layout | 2+3 Layout |
| Power-adjustable Seats | Driver & Passenger Power Seats |
| Driver Seat Adjustment | Fore/aft, Backrest, Height Adjustment |
| Driver Seat Partial Adjust | Headrest, Lumbar Support |
| Passenger Seat Adjustment | Fore/aft, Backrest Adjustment |
| Passenger Seat Partial Adjust | Headrest |
| Second Row Adjustment | Backrest Angle Adjustment |
| Front Seat Functions | Heated Seats |
| Rear Seat Split Ratio | 40/60 Split Folding |
| Front & Rear Armrest | Front & Rear Armrest |
| Rear Cup Holders | ● Standard |
| Smart Connectivity | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Central Touchscreen Size | 15.6 Inches |
| Satellite Navigation | ● Standard |
| Roadside Assistance | ● Standard |
| Bluetooth Hands-free | ● Standard |
| Smartphone Integration | Apple CarPlay, Huawei HiCar, Carlink |
| Vehicle Network | ● Standard |
| 4G/5G Cellular Network | 4G Network |
| OTA Software Update | ● Standard |
| Face Recognition | ● Standard |
| Voiceprint Recognition | ● Standard |
| Voice Control System | ● Standard |
| Wake-free Voice Control | ● Standard |
| Multi-zone Voice Recognition | 4 Voice Zones |
| Continuous Voice Dialogue | ● Standard |
| Screen Voice Control | ● Standard |
| Voice Assistant Wake Word | Hi Toyota |
| Onboard Wi-Fi Hotspot | ● Standard |
| Audio & Entertainment | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| App Store | ● Standard |
| USB-C Ports | 3 Front, 2 Rear Ports |
| USB Charging Power | Front 45W, Rear 15W |
| Speaker Count | 6 Speakers |
| Lighting Configuration | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Low Beam Headlights | LED Low Beams |
| High Beam Headlights | LED High Beams |
| Daytime Running Lights | ● Standard |
| Adaptive High-low Beam | ● Standard |
| Auto Headlights | ● Standard |
| Headlight Height Adjustment | ● Standard |
| Interior Ambient Light | 64-color Ambient Lighting |
| Headlight Delay Off | ● Standard |
| Windows & Mirrors | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Power Windows | Front & Rear Power Windows |
| One-touch Auto Window | All Windows One-touch Up/Down |
| Window Anti-pinch Function | ● Standard |
| Side Mirror Functions | Power Adjust, Heated, Power Fold, Auto Fold When Locked |
| Sun Visor Vanity Mirror | Illuminated Driver & Passenger Vanity Mirrors |
| Rear Windshield Wiper | ● Standard |
| Air Conditioning & Fridge | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| AC Control Type | Automatic Climate Control |
| Rear Air Vents | ● Standard |
| Climate Zones | Dual-zone Climate Control |
| PM2.5 Air Filter | ● Standard |
| Fragrance System | ● Standard |
| Intelligent System | |
| ADAS Operating System | Toyota Pilot ADAS System |
| Onboard Chip | Qualcomm Snapdragon 8155 |
| Mobile App Remote Control | Vehicle Monitoring, Remote Control, Service Booking, Digital Key |
| Exterior Cameras Count | 5 External Cameras |
| Interior Camera Count | 1 Interior Camera |
| Ultrasonic Radars | 8 Ultrasonic Radars |
| Millimeter-wave Radars | 3 Millimeter-wave Radars |
| Optional Packages | |
| Standard/Optional Mark | ● Standard ○ Not Optional |
| Custom Optional Packages | Optional Exterior, Interior, Wheels, Brakes |
