2026 RAV4 Hybrid 2.0L 2WD Luxury Edition
1. Advanced 5th-gen THS hybrid powertrain: 144kW total output, WLTC fuel consumption 4.59L/100km
2. Spacious family layout: 2690mm wheelbase, 580L standard cargo volume
3. Full TSS 3.0 safety suite + 15.6-inch touchscreen with 8155 chip
Product Details
| Basic Information | |
| Manufacturer | FAW Toyota |
| Vehicle Class | Compact SUV |
| Energy Type | Hybrid |
| Launch Date | Nov-25 |
| Engine | 2.0L 152PS L4 Hybrid |
| Max. Power (kW) | 144 kW |
| Engine Max. Torque (N·m) | 188 N·m |
| Electric Motor Max. Torque (N·m) | 206 N·m |
| Transmission | E-CVT Continuously Variable Transmission |
| Overall Length×Width×Height (mm) | 4620×1855×1680 mm |
| Body Structure | 5-door 5-seater SUV |
| Max. Speed (km/h) | 180 km/h |
| WLTC Comprehensive Fuel Consumption (L/100km) | 4.59 L/100km |
| Vehicle Warranty Period | 3 years or 100,000 km |
| Body | |
| Length (mm) | 4620 mm |
| Width (mm) | 1855 mm |
| Height (mm) | 1680 mm |
| Wheelbase (mm) | 2690 mm |
| Front Track (mm) | 1600 mm |
| Rear Track (mm) | 1620 mm |
| Body Structure | SUV |
| Number of Doors | 5 |
| Door Opening Method | Swing Door |
| Number of Seats | 5 |
| Curb Weight (kg) | 1660 kg |
| Gross Vehicle Weight (kg) | 2155 kg |
| Fuel Tank Capacity (L) | 55.0 L |
| Minimum Turning Radius | 5.7 m |
| Engine | |
| Engine Model | M20H |
| Displacement (mL) | 1987 mL |
| Displacement (L) | 2.0 L |
| Intake Form | Naturally Aspirated |
| Engine Layout | Transverse |
| Cylinder Arrangement | Inline |
| Number of Cylinders | 4 |
| Number of Valves per Cylinder | 4 |
| Compression Ratio | 14 |
| Valve Train | DOHC |
| Max. Horsepower (Ps) | 152 Ps |
| Max. Power (kW) | 112 kW |
| Max. Net Power (kW) | 112kW (152Ps) |
| Max. Power Speed (rpm) | 6000 rpm |
| Max. Torque (N·m) | 188 N·m |
| Max. Torque Speed (rpm) | 4400-5200 rpm |
| Engine Specific Technology | VVT-iE |
| Fuel Type | Hybrid |
| Fuel Grade | 92# |
| Fuel Supply Method | Combined Injection |
| Cylinder Head Material | Aluminum Alloy |
| Cylinder Block Material | Aluminum Alloy |
| Emission Standard | China VI |
| Electric Motor | |
| Electric Motor Description | Hybrid 113 Horsepower |
| Motor Type | Permanent Magnet/Synchronous |
| Total Electric Motor Power (kW) | 83kW (113Ps) |
| Total Electric Motor Horsepower (Ps) | 113 Ps |
| Total Electric Motor Torque (N·m) | 206 N·m |
| Front Electric Motor Max. Power (kW) | 83 kW |
| Front Electric Motor Max. Torque (N·m) | 206 N·m |
| System Combined Power (kW) | 144 kW |
| Number of Drive Motors | Single Motor |
| Motor Layout | Front-mounted |
| Battery/Charging | |
| Battery Type | Ternary Lithium Battery |
| Cell Brand | Taixing Energy |
| Battery Pack Warranty | 8 years or 200,000 km |
| Transmission | |
| Transmission Description | E-CVT Continuously Variable Transmission |
| Number of Gears | Continuously Variable |
| Transmission Type | Electronic Continuously Variable Transmission (E-CVT) |
| Chassis/Steering | |
| Drive Mode | Front-Wheel Drive |
| Front Suspension Type | MacPherson Independent Suspension |
| Rear Suspension Type | Double Wishbone Independent Suspension |
| Steering Type | Electric Power Steering |
| Body Structure | Body-on-Frame Construction |
| Wheels/Brakes | |
| Front Brake Type | Ventilated Disc |
| Rear Brake Type | Solid Disc |
| Parking Brake Type | Electronic Parking Brake |
| Front Tire Specification | 235/60 R18 |
| Rear Tire Specification | 235/60 R18 |
| Spare Tire Specification | ● Non-full Size |
| Spare Tire Placement | ● Hidden Type |
| Active Safety | |
| ABS Anti-lock Braking System | ● Standard |
| Brake Force Distribution (EBD/CBC, etc.) | ● Standard |
| Brake Assist (EBA/BA, etc.) | ● Standard |
| Traction Control (TCS/ASR, etc.) | ● Standard |
| Electronic Stability Program (ESP/DSC, etc.) | ● Standard |
| Active Safety Warning System | ● Lane Departure Warning ● Forward Collision Warning ● Rear Collision Warning ● Reverse Side Warning ● DOW Door Open Warning |
| Active Braking | ● Standard |
| Blind Spot Monitoring | ● Standard |
| Lane Keeping Assist System | ● Standard |
| Lane Centering Keep | ● Standard |
| Drowsy Driving Alert | ● Standard |
| Active DMS Drowsy Detection | ● Standard |
| Road Traffic Sign Recognition | ● Standard |
| Passive Safety | |
| Front Airbags | ● Driver's Seat ● Passenger's Seat |
| Side Airbags | ● Front |
| Side Curtain Airbags | ● Standard |
| Front Knee Airbags | ● Driver's Seat |
| Center Airbag | ● Front |
| Seatbelt Unfastened Alert | ● Standard |
| Tire Pressure Monitoring System | ● Tire Pressure Display |
| Child Seat Interface (ISOFIX) | ● Standard |
| Assistance/Control Configuration | |
| Parking Radar | ● Front ● Rear |
| Driving Assist Image | ● Reverse Camera ● 360° Panoramic Camera |
| Cruise Control System | ● Cruise Control ● Adaptive Cruise Control ● Full-Speed Adaptive Cruise Control |
| Assisted Driving Level | ● Level 2 |
| Auto Hold (AUTOHOLD) | ● Standard |
| Hill Start Assist (HAC) | ● Standard |
| Driving Mode Selection | ● Sport ● Personalized ● ECO/Economic ● Standard Comfort |
| Exterior Configuration | |
| Sunroof Type | ● Openable Panoramic Sunroof |
| Aluminum Alloy Wheels | ● Standard |
| Interior Configuration | |
| Steering Wheel Material | ● Leather |
| Steering Wheel Adjustment | ● Up/Down + Front/Rear |
| Steering Wheel Functions | ● Multi-Function Control |
| Shift Method | ● Electronic Gear Lever |
| LCD Instrument Style | ● Full LCD |
| LCD Instrument Size (Inches) | ● 8.8 |
| Comfort/Anti-Theft Configuration | |
| Electric Rear Tailgate | ● Standard |
| Electric Rear Tailgate Position Memory | ● Standard |
| Engine Anti-Theft System | ● Standard |
| Central Door Lock | ● Standard |
| Remote Key Type | ● Smart Remote Key ● Mobile Bluetooth Key ● NFC/RFID Key |
| Keyless Entry | ● Front |
| Keyless Start | ● Standard |
| Remote Start | ● Standard |
| Factory ETC | ● Standard |
| Wireless Phone Charging | ● First Row 50W |
| Luggage Compartment 12V Power Outlet | ● Standard |
| Seat Configuration | |
| Seat Material | ● Faux Leather |
| Seat Layout | ● 2+3 |
| Electric Seat Adjustment | ● Driver's Seat ● Passenger's Seat |
| Driver's Seat Overall Adjustment | ● Front/Rear Movement ● Backrest Angle ● Height Adjustment |
| Driver's Seat Partial Adjustment | ● Headrest ● Lumbar |
| Passenger's Seat Overall Adjustment | ● Front/Rear Movement ● Backrest Angle |
| Passenger's Seat Partial Adjustment | ● Headrest |
| Second Row Seat Overall Adjustment | ● Backrest Angle Adjustment |
| Front Seat Functions | ● Heating |
| Front/Rear Armrest | ● Front ● Rear |
| Rear Cup Holders | ● Standard |
| Rear Seat Folding Ratio | ● 40:60 |
| Smart Connectivity | |
| Central Control Screen Size (Inches) | ● 15.6 |
| Satellite Navigation System | ● Standard |
| Roadside Assistance Service | ● Standard |
| Bluetooth/Car Phone | ● Standard |
| Phone Interconnection Mapping | ● CarPlay ● HUAWEI HiCar ● Carlink |
| Internet of Vehicles | ● Standard |
| 4G/5G Network | ● 4G |
| OTA Upgrade | ● Standard |
| Facial Recognition | ● Standard |
| Voiceprint Recognition | ● Standard |
| Voice Recognition Control System | ● Standard |
| Voice Wake-Up Free Function | ● Standard |
| Voice Zone Wake-Up Recognition Function | ● Four Zones |
| Continuous Voice Recognition | ● Standard |
| What You See Is What You Say | ● Standard |
| Voice Assistant Wake Word | Hello Toyota |
| Wi-Fi Hotspot | ● Standard |
| Audio-Visual Entertainment | |
| App Store | ● Standard |
| Number of USB/Type-C Interfaces | ● 3 Front ● 2 Rear |
| Max. Charging Power of USB/Type-C | Front 45W Rear 15W |
| Number of Speakers | ● 6 |
| Lighting Configuration | |
| Low Beam | ● LED |
| High Beam | ● LED |
| Daytime Running Lights | ● Standard |
| Adaptive High/Low Beam | ● Standard |
| Automatic Headlights | ● Standard |
| Headlight Height Adjustment | ● Standard |
| Interior Ambient Light | ● 64 Colors |
| Headlight Delay Off | ● Standard |
| Glass/Mirrors | |
| Power Windows | ● Front ● Rear |
| One-Touch Window Lift | ● Full Car |
| Window Anti-Pinch Function | ● Standard |
| Exterior Mirror Functions | ● Electric Adjustment ● Heating ● Electric Folding ● Auto Folding on Lock |
| Interior Vanity Mirror | ● Driver's Seat + Illuminated ● Passenger's Seat + Illuminated |
| Rear Wiper | ● Standard |
| Air Conditioning/Refrigerator | |
| Air Conditioning Control Method | ● Automatic |
| Rear Air Vents | ● Standard |
| Temperature Zone Control | ● Dual-Zone Air Conditioning |
| Interior PM2.5 Filter | ● Standard |
| Interior Fragrance Device | ● Standard |
| Intelligent Configuration | |
| Assisted Driving Operating System | ● Toyota Pilot |
| On-Board Smart Chip | ● Qualcomm Snapdragon 8155 |
| Mobile App Remote Control | ● Vehicle Monitoring ● Remote Control ● Service Reservation ● Digital Key |
| Number of Exterior Cameras | ● 5 |
| Number of Interior Cameras | ● 1 |
| Number of Ultrasonic Radars | ● 8 |
| Number of Millimeter Wave Radars | ● 3 |
| Optional Package | |
| Custom Optional | Optional Appearance, Interior, Wheels, Brakes |
| ETC | ○ Optional |
