Technical Parameters
Overall Dimensions Length × Width × Height | 8160×2530×3590mm. |
Main Parameters of Fire Protection System | |
Water tank capacity | 5000kg |
Class B Foam | 1000kg (or other specifications) |
Fire pump rated flow at 10bar pressure | 60L/s |
Fire monitor flow rate | 48L/s |
Maximum Speed | 95km/h, with cruise control and electronic speed limitation |
Number of Occupants | 6 people (2+4) |
Chassis and Crew Cab | |
Specification Model | Sinotruk Group Howo ZZ5206N471GF5 |
Drive Configuration | 4X2 |
Chassis Allowable Load | 20100kg, Front Axle: 7100kg, Rear Axle: 13000kg. |
Wheelbase | 4500mm |
Engine | MC07H.35-60 six-cylinder, turbocharged intercooled, high-pressure common rail diesel engine |
Rated Power | 257kW |
Maximum Torque | 1400Nm@1200-1800rpm |
Emission Standard | National VI |
Displacement | 7360ml |
Transmission | Manual transmission, 9 forward gears, 1 reverse gear |
Steering System | BOSCH steering gear, multifunctional steering wheel, steering wheel height and angle adjustable. |
Brake System | With Anti-lock Braking System (ABS), dual-circuit air brake with spring energy storage parking brake, and engine exhaust brake. |
Electrical System | Whole vehicle 24V DC, generator: 28V/80A 2.2kW, batteries: 2×12V/180Ah. |
Fuel | Diesel tank capacity: 200L. |
Tires | 295/80R22.5, 2 tires on the first axle, 4 tires on the second axle, 1 spare tire. |
Other Cab Configurations | Original chassis double-row four-door, flat-head cab with all-steel frame welded structure, seating capacity: 6 people (1+1+4). Driver's air suspension seat; upper steps and safety handrails on both sides of the rear row; rear 4 seats are equipped with6.8-9L air suspension bracket, cab electric-hydraulic integrated tilting, equipped with air conditioning, main power switch, central locking, power windows, etc. |
Instruments & Meters | Standard instruments, indicator lights and switches are installed on the original chassis instrument panel (including odometer, tachometer, oil pressure gauge & alarm, fuel/urea level gauge, turn signal, brake system alarm, etc.); additionally equipped with alarm system, 360° panoramic image system, driving recorder, roller shutter door/step indicator lights, upper power switch, tire pressure display, etc |
