Corolla Cross 2026 2.0L Smart Hybrid (HEV) Pioneer Edition
5th-gen THS hybrid system: 2.0L Atkinson cycle engine, total system power 144kW, WLTC fuel consumption 4.56L/100km, compatible with 92# gasoline
TNGA-C compact SUV platform: 4460×1825×1625mm, wheelbase 2640mm, 5-seater layout, stable torsion beam rear suspension
Standard TSS 3.0 safety suite: L2-level intelligent driving assist, pre-collision system, lane keeping & adaptive cruise control
Product Details
| 上海极度福泰克汽车科技有限公司 | |
| Shanghai DTspace Futech Auto Tech Co., Ltd. | |
| Corolla Cross 2026 2.0L Smart Hybrid (HEV) Pioneer Edition | |
| Basic Information | |
| Full Model Name | FAW Toyota Compact HEV SUV |
| Manufacturer | FAW Toyota |
| Vehicle Class | Compact SUV |
| Energy Type | Hybrid Electric (HEV) |
| Launch Date | Oct-25 |
| Engine Assembly | 2.0L 158PS Inline-4 Hybrid |
| Max Power(kW) | 144 kW |
| Engine Max Torque(N·m) | 188 N·m |
| Motor Max Torque(N·m) | 206 N·m |
| Transmission | E-CVT |
| Length×Width×Height(mm) | 4460×1825×1625 mm |
| Body Structure | 5-door 5-seat SUV |
| Max Speed(km/h) | 180 km/h |
| WLTC Combined Fuel Consumption(L/100km) | 4.56 L/100km |
| Body | |
| Length(mm) | 4460 mm |
| Width(mm) | 1825 mm |
| Height(mm) | 1625 mm |
| Wheelbase(mm) | 2640 mm |
| Front Track(mm) | 1565 mm |
| Rear Track(mm) | 1580 mm |
| Body Type | SUV |
| Number of Doors | 5 doors |
| Door Opening Type | Conventional Door |
| Seating Capacity | 5 seats |
| Curb Weight(kg) | 1425 kg |
| Gross Vehicle Weight(kg) | 1945 kg |
| Fuel Tank Capacity(L) | 36.0 L |
| Luggage Compartment Volume(L) | 427 L |
| Minimum Turning Radius | 5.2 m |
| Engine Assembly | |
| Engine Model | M20G |
| Displacement(mL) | 1987 mL |
| Displacement(L) | 2.0 L |
| Intake Type | Naturally Aspirated |
| Engine Layout | Transverse Layout |
| Cylinder Arrangement | Inline |
| Number of Cylinders | 4 cylinders |
| Valves Per Cylinder | 4 valves |
| Compression Ratio | 14 |
| Valve Mechanism | DOHC |
| Max Horsepower(Ps) | 158 PS |
| Max Power(kW) | 116 kW |
| Max Net Power(kW) | 116 kW (158 PS) |
| Max Power Speed(rpm) | 6000 rpm |
| Max Torque(N·m) | 188 N·m |
| Max Torque Speed(rpm) | 4400-5200 rpm |
| Special Engine Technology | VVT-iE |
| Fuel Type | Hybrid |
| Fuel Grade | 92-octane |
| Fuel Supply | Dual Injection (Port + Direct) |
| Cylinder Head Material | Aluminum Alloy |
| Cylinder Block Material | Aluminum Alloy |
| Emission Standard | China-VI b |
| Motor | |
| Motor Description | Hybrid 113 PS |
| Motor Type | Permanent Magnet Synchronous |
| Total Motor Power(kW) | 83 kW (113 PS) |
| Total Motor Horsepower(Ps) | 113 PS |
| Total Motor Torque(N·m) | 206 N·m |
| Front Motor Max Power(kW) | 83 kW |
| Front Motor Max Torque(N·m) | 206 N·m |
| System Combined Power(kW) | 144 kW |
| Number of Drive Motors | Single-motor |
| Motor Layout | Front |
| Battery / Charging | |
| Battery Type | Ternary Lithium-ion Battery |
| Cell Brand | CATL Jiangsu |
| Battery Pack Warranty | 8 years or 200,000 km |
| Transmission | |
| Transmission Description | E-CVT |
| Number of Gears | CVT |
| Transmission Type | Electronic Continuously Variable Transmission (E-CVT) |
| Chassis/Steering | |
| Drive Mode | Front-engine Front-wheel Drive |
| Front Suspension | MacPherson Independent Suspension |
| Rear Suspension | Torsion-beam Non-independent Suspension |
| Steering Type | Electric Power Steering |
| Body Structure | Monocoque Body |
| Wheels / Braking | |
| Front Brake Type | Ventilated Disc |
| Rear Brake Type | Solid Disc |
| Parking Brake Type | Electronic Parking Brake |
| Front Tire Specification | 215/60 R17 |
| Rear Tire Specification | 215/60 R17 |
| Active Safety | |
| Anti-lock Braking System ABS | Standard |
| Electronic Brake-force Distribution EBD | Standard |
| Emergency Brake Assist EBA | Standard |
| Traction Control System TCS | Standard |
| Electronic Stability Program ESP | Standard |
| Active Safety Warning System | Lane Departure Warning, Forward Collision Warning |
| Automatic Emergency Braking | Standard |
| Lane Keeping Assist | Standard |
| Lane Centering Assist | Standard |
| Traffic Sign Recognition | Standard |
| Passive Safety | |
| Front Airbags | Driver, Front Passenger |
| Side Airbags | Front Row |
| Side Curtain Airbags | Standard |
| Front Knee Airbags | Driver |
| Seat-belt Reminder | Standard |
| Tire Pressure Monitoring System | Tire Pressure Display |
| ISOFIX Child Seat Anchors | Standard |
| Auxiliary/Control Configuration | |
| Cruise Control | Constant-speed Cruise, Adaptive Cruise Control, Full-speed Adaptive Cruise Control |
| ADAS Level | Level 2 |
| Auto Hold | Standard |
| Hill-start Assist Control HAC | Standard |
| Drive Mode Selection | Sport, Standard Comfort, ECO/Economy |
| External configuration | |
| Aluminum Alloy Wheels | Standard |
| Internal configuration | |
| Steering Wheel Material | Plastic |
| Steering Wheel Adjustment | Tilt & Telescopic |
| Steering Wheel Functions | Multi-function Controls |
| Shift Type | Mechanical Shift Lever |
| Instrument Cluster Type | Full LCD Instrument |
| Instrument Screen Size(inch) | 7 inch |
| Comfort/Security Configuration | |
| Engine Immobilizer | Standard |
| Central Door Lock | Standard |
| Remote Key Type | Smart Remote Key |
| Keyless Entry | Front Row |
| Keyless Start | Standard |
| Seat configuration | |
| Seat Material | Fabric |
| Seat Layout | 2+3 Layout |
| Driver Main Adjustment | Fore-aft, Backrest Angle, Height |
| Driver Auxiliary Adjustment | Headrest |
| Passenger Main Adjustment | Fore-aft, Backrest Angle |
| Passenger Auxiliary Adjustment | Headrest |
| Rear Armrest | Front Row |
| Rear Cup Holders | Standard |
| Rear Seat Folding Ratio | 40:60 Split |
| Intelligent interconnection | |
| Central Control Screen Size(inch) | 10.25 inch |
| Roadside Assistance | Standard |
| Hands-free Phone | Standard |
| Smartphone Integration | CarPlay, HUAWEI HiCar, Carlink |
| OTA Update | Standard |
| Video entertainment | |
| USB / Type-C Port Quantity | Front 1 port |
| Number of Speakers | 4 speakers |
| Lighting configuration | |
| Low-beam Headlight | Halogen |
| High-beam Headlight | Halogen |
| Daytime Running Light | Standard |
| Adaptive High-low Beam | Standard |
| Auto Headlamp | Standard |
| Headlight Height Adjustment | Standard |
| Glass / Rearview Mirror | |
| Power Windows | Front, Rear |
| One-touch Window Up-down | Full-vehicle |
| Window Anti-pinch | Standard |
| Exterior Mirror Functions | Electric Adjustment |
| Vanity Mirror | Driver without light, Front passenger without light |
| Rear Wiper | Standard |
| Air conditioner / Refrigerator | |
| AC Control Type | Automatic |
| PM2.5 Filter | Standard |
| Intelligent configuration | |
| ADAS Operating System | Toyota Pilot |
| Mobile App Remote Control | Service Booking, Vehicle Monitoring, Remote Control |
| Exterior Camera Quantity | 1 |
| Millimeter-wave Radar Quantity | 1 |
